XLR connectors make it easy to attach the splitter snake cable to amps and mixers without additional converters. These snakes are rack-mounted, so youll need a rack case to go along with it. Each pair of heavy duty conductors is individually shielded, producing crystal clear sound while rejecting extraneous noise. We decided to purchase the 32 channel splitter snake with 25 and 6 XLR tails. Splitter snake cables feature the basic Y splitter setup. Splitter snakes are available from 16 channel to 32 channels. Splitter snake cables from Seismic Audio Speakers are available in a variety of sizes to meet your band's needs. You can plug an XLR or a 1/4" in to the box end of the snake. The cable ends on the fantails are all male XLR, while the stage box consists of all female XLR and 1/4" combo jacks. These splitter cables are straight send snakes and do not have any returns. These splitter snake cables do not have splitter transformers, ground-lift switches, or multi-pin disconnects. They each have a stage box and two hardwired short trunks with fantails. The fantail is built with male XLR shells.These snakes are your basic hardwired Y splitters. The female XLR / 1/4" panel jacks on the box are locking coiled spring style with non metallic bodies. There is a mesh hanger at the fantail end. You will find strain relief at both the stage box and fantail end of the snake. Both the main trunk and split trunk are built with cable that is individually shielded pairs, 22 guage, high copper purity conductors with aluminum foil shield and trace wire. Both fantails are well labeled and grouped by color. Rack Mountable Splitter Snake Cables have the Stage Box rack mountable for convenience and ease of transport. Buy splitter snake cables for the best connection between the stage and the mixer. Each model comes with the option of two 15 foot trunks or a 15 foot and a 30 foot trunk. Splitter snakes are available in 16 channel, 24 Channel and 32 channel configurations. Conforms to the latest DMX/RDM standards.Seismic Audio offers 2 different kinds of Splitter Snake Cable, Standard and Rack Mountable! Splitter snake cables from Seismic Audio Speakers are available in a variety of sizes to meet your band's needs.LED indicators for DMX, Power, DMX Termination and DMX/RDM data activity.Output circuits are EMI filtered and current limited to protect against short circuits.Output XLR connector options of 5 pin, 3pin or mixed.Five / Ten EIA485 data outputs suitable for DMX512A compatible protocols.DMX thru connector allowing more MDR splitters to be cascaded.Integrated input termination switch with termination active LED.Single RS422/EIA485 input suitable for DMX512A compatible protocols.Sturdy folded metal case for the rack-mount versions.Dual Headphone Monitoring, No Splitter Required. Lightweight, high strength moulded plastic case for the truss version. On the rear panel youll find eight XLR/TRS combo inputs (with +48V phantom power), with additional line.Fully opto/earth-isolated input & individually opto/earth isolated outputs.Safety Wire attachment point on Truss Mount version.Internal 85-264v AC 45-65Hz universal power supply with UL approval.The most ‘future-proof’ DMX-512A splitter available.īuy it now as a DMX-512A splitter with fully isolated outputs.Īdd RDM now or next week, next year or whenever you need it.If you never need RDM then you haven’t wasted your money. Buy it now without RDM installed (Don’t pay for something you don’t need).World’s first RDM field upgradeable DMX splitter.The fully isolated DMX outputs ensure that no matter which vintage DMX products you have, you will not have any earth loop problems. Ideal for those situations where cable simplification is necessary, the truss mount unit is designed to fit standard 50mm (2") tubing.
#Xlr splitter rack portable#
The portable model offers truss mounting capabilities either via velcro straps or the separately available hook-clamp adaptor. A dedicated 10-way rack mount permanent installation model is also available with Ethercon RJ45 input and output connectors. A pass through connector allows multiple units to be connected together to create a greater number of isolated outputs. If purchased without RDM it can be installed at any time in the future, using just a screwdriver.Īll MDR units offer an inbuilt DMX termination switch and a choice of 5-pin or 3-pin XLR style input and output connectors. 2 Pack XLR Splitter 1 Female to 2 Male,XLR Splitter Cable,1. The MDR range can be purchased with or without RDM functionality installed. These splitters are the world's first field upgradeable splitters to offer RDM functionality as an option. The MDR range of splitters are DMX512A (ANSI E1-11) compatible data splitters available in a 19” rack mount model or in a compact portable model.
